NPT Adapters yog ib qho khoom siv nrov tshaj plaws ntawm cov chaw nres tsheb hauv hydraulic CNC tshuab thiab txhaj tshuaj molding machine, Txhua NPT adapters yog machined nrog American National Standard Yeeb nkuaj xov hu ua NPT style fittings mus cuag roj chaw nres nkoj. Jiayuan fittings muab NPT Nipples, NPT ntsaws, NPT lub khawm, NPT Couplings, NPT hloov reducer, txuas ntxiv thiab adapters rau khub niam txiv nrog cov sib txuas NPT kawg, lub cev zoo li Ncaj adapters, Luj Adapters, Tees adapters, Adjustable adapters thiab lwm yam.
NPT taper xov fittings feem ntau yog siv nyob rau hauv daim ntaub ntawv siv, nws yog qhov yooj yim hlau rau hlau sealing tsim rau ib lub seal.NPT threads, thaum dhos tsis muaj sealant, tawm ntawm txoj kab kev sib tsoo ntawm qhov crest-root junction raws li qhia hauv F1 . Los kaw cov dej kua ntsev, NPT threads yuav tsum muaj kev sib ceg.
Daim duab F1 - NPT: Ciaj ntswj ntswj, Tsis muaj Crest-Cag Sib cuag, Flank Ntaus Xwb
Xov NPT yog ANSI B1.20.1, FED-STD-H28 / 7
Xov NPTF txuj yog SAE J476, ANSI B1.20.3, FED-STD-H28 / 8
NPTF threads (Dryseal), ntawm qhov tod tes, thaum twg dho, tsis txhob tawm ntawm txoj kev xaav. Qhov no yog vim tias lawv tau tswj cov khoom siv hauv cov kab thiab lub hauv paus, ua kom muaj hlau-los-hlau-kab-sib txuas ua ntej, lossis cia li txiv neej-poj niam xov flanks ua kev sib cuag raws li pom hauv F2. Raws li qhov ntxiv zawm, xov crests yog flattened kom txog rau thaum cov flanks kuj ua hlau-rau-hlau hu raws li pom hauv F3 F3. Yog li, qhov tsawg tshaj plaws, tsis muaj ib qho kev tawm mus sab nraud rau cov kua xau, yog tias txhua qhov chaw tsis muaj qhov tsis txaus thiab qhov ntev. Hauv kev muaj tiag, qhov no tsis yog cov ntaub ntawv thiab ib qho sealant / lubricant yog tsim nyog los ua kom tau ib qho xau dawb, txawm tias NPTF threads. Cov txhuam hniav / lub nplhaib ua rau tag nrho cov txhij txhua nyob rau hauv cov chaw uas cuam tshuam lub foob thiab kuj muab lubrication kom yooj yim tuaj yeem ua kom tsawg thiab gallim tsawg.
