Cov Khoom Muag Khoom: 5FLW-S / IN Hydraulic SAE Flange 3000PIS Inch Tube
Kev Lag Luam Cov Qauv: SAE J518, ISO 6162
Txuas E rau F style: SAE Flange 3000PIS / INCH SOCKET-WELD TUBE
Puab: Ncaj
Kev ntsuas ua haujlwm siab: SAE code 61 yog 2.5 txog 31.5 Mpa; SAE code 62 yog 40 Mpa.
Cov Khoom Siv Fittings: tooj dag; Cov hlau; Stainless Hlau
Daim ntawv thov: Cov khoom siv ua liaj ua teb, tsheb txheej txheem, kev hloov tshuaj, Siv khoom siv, hloov roj, Hydraulic, tsim khoom siv, tubrog nkoj, Siv cov khoom siv, Khoom siv txawb, Oilfield, ntim, Tsheb thauj mus los
5FLW-S / HAUV SAE Flange 3000 PSI Adapter Fittings Qhov Loj Qhov Loj Cov Lus Qhia raws li hauv qab no
NTU TSIS MUAJ. | O | D | YAM | |||||
FLANGE SIZE | O-RING | WELD TUBE OD D | A | D1 | D2 | L | ||
5FLW-08S / HAUV | 1/2 " | O210 | 1/2 " | 7. Peb muaj 7 | 30.2 | 23,9 | 13. 13 | |
5FLW-12-08S / HAUV | 3/4 " | O214 | 1/2 " | 7. Peb muaj 7 | 38.1 | 31,7 | 15 15 | |
5FLW-12S / HAUV | 3/4 " | O214 | 3/4 " | 7. Peb muaj 7 | 38.1 | 31,7 | 15 15 | |
5FLW-16-12S / HAUV | 1 " | O219 | 3/4 " | 8.2 | 44.4 | 38 | 15 15 | |
5FLW-16S / HAUV | 1 " | O219 | 1 " | 8.2 | 44.4 | 38 | 15 15 | |
5FLW-20-16S / HAUV | 1,1 / 4 " | O222 | 1 " | 8.2 | 50.8 | 43.2 | 15 15 | |
5FLW-20S / HAUV | 1,1 / 4 " | O222 | 1,1 / 4 " | 8.2 | 50.8 | 43.2 | 15 15 | |
5FLW-24-16S / HAUV | 1,1 / 2 " | O225 | 1 " | 8.2 | 60.3 | 50.3 | 20 20 | |
5FLW-24-20S / HAUV | 1,1 / 2 " | O225 | 1,1 / 4 " | 8.2 | 60.3 | 50.3 | 20 20 | |
5FLW-24S / HAUV | 1,1 / 2 " | O225 | 1,1 / 2 " | 8.2 | 60.3 | 50.3 | 20 20 | |
5FLW-32-20S / HAUV | 2 " | O228 | 1,1 / 4 " | 9,8 | 71.4 | 62.2 | 20 20 | |
5FLW-32-24S / HAUV | 2 " | O228 | 1,1 / 2 " | 9,8 | 71.4 | 62.2 | 20 20 | |
5FLW-32S / HAUV | 2 " | O228 | 2 " | 9,8 | 71.4 | 62.2 | 20 20 |
