Flare tube fittings
Flare tube haum adapters yog ib txoj hlua khi uas tsis muaj kev cia siab, cov hlau txuas rau hlau txuas ntawm tubing thiab piping system, nws yog ib hom kev sib txuam fittings.
Qhov kev sib dhos yog, tus flare nut kom ruaj khov rau qhov flared tubing taper kawg rooj lub flared tube haum, tsim lub siab tawv, ua kom txeeb seev.
Lub flare fittings yog siv rau tooj liab yeeb nkab, yeeb nkab yeeb nkab thiab cov yeeb nkab tsis xa cov hlua.Qhov txawv txawv tebchaws thoob ntiaj teb raws li nram no:
SAE J512, SAE J 513 txuj ci: tooj dag 45 ° flare fittings yog siv rau tooj liab tub yees ntawm cov tub yees, tsheb hluav taws xob txoj kab, roj av nkos, lossis roj.
SAE J514, SAE J516 tus qauv: 37 ° Flare JIC tube fittings thiab adapters siv rau steel thiab stainless raj ntawm kev tsim kho, kev ua liaj / teb, cov khoom siv thiab kev xa cov cav.
JIS B8363 txuj ci: 30 ° flare BSPP xov raj fittings li hose adapter rau hydraulic hose sib tov nyob rau hauv hydraulic kua kov kev txuas.
Komatsu tuam txhab tus qauv: 30 ° flare metric xov raj fittings li hose adapters rau Komatsu thiab OEM mobile khoom fittings nyob hauv txoj kev ua lag luam.
JIayuan ua ntau hom kev flaring fittings raws li cov qauv saum toj no, kuj muaj muag ntu 37 ° flare JIC tube fittings thiab adapters. Flare haum cov qauv xov xwm raws li nram no:
Thread Sizes G ¼ "los ntawm G1" nrog kev ua haujlwm kom txog 5000 psi.
Qhov ntau thiab tsawg ntawm M14 x 1.5 mus txog M33 x 1.5 nrog kev ua haujlwm kom txog 4000 psi.
Xovtooj loj UNF1 / 8 "- UNF2 ½" nrog kev ua haujlwm kom txog 7500 psi.
