Cov khoom lag luam: JIC hydraulic haum siv rau lub raj txuas txuas ntawm lub zog hluav taws xob
Cov khoom lag luam: ISO 8434-2, SAE J514.
Cov khoom siv: carbon hlau, stainless hlau lossis tooj liab alloy.
JIC lub raj xaus rau lwm qhov kawg txuas raws li kev ua raws: BSP Captive foob E, G, H hom, ISO 6149 series fittings, JIS B2351 fittings, ISO 11926 thiab SAE J1926 ORB fittings, DIN 3852 thiab ISO 1179 fittings, ISO 9974 fittings thiab lwm yam.
1JN9-LOS 90 ° JIC MALE 74 ° CONE NROG O-RING / NPT MALE Daim duab qhia qhov loj me raws li hauv qab no:
NTU TSIS MUAJ. | NKAWV | O O-RING | YAM | ||||||
E | F | E | A | B | S1 | ||||
1JN9-10-06OR | 7/8 "X14 | Z3 / 8 "X18 | 13X1 | 37.8 | 32,5 | 22 | |||
1JN9-10-08OR | 7/8 "X14 | Z1 / 2 "X14 | 13X1 | 37.8 | 37.3 | 22 | |||
1JN9-10-12OR | 7/8 "X14 | Z3 / 4 "X14 | 13X1 | 41 | 44 | 27. Muaj 27 leej | |||
1JN9-12OR | 1.1 / 16 "X12 | Z3 / 4 "X14 | 17X1 | 44.2 | 44 | 27. Muaj 27 leej | |||
1JN9-12-06OR | 1.1 / 16 "X12 | Z3 / 8 "X18 | 17X1 | 44.2 | 36,5 | 27. Muaj 27 leej | |||
1JN9-12-08OR | 1.1 / 16 "X12 | Z1 / 2 "X14 | 17X1 | 44.2 | 40 | 27. Muaj 27 leej | |||
1JN9-12-16OR | 1.1 / 16 "X12 | Z1 "X11.5 | 17X1 | 49 | 50. | 33 | |||
1JN9-14-12OR | 1.3 / 16 "X12 | Z3 / 4 "X14 | 19X1.5 | 47,5 | 45 | 30. 30 | |||
1JN9-16OR | 1.5 / 16 "X12 | Z1 "X11.5 | 22X1,5 | 49 | 50. | 33 | |||
1JN9-16-12OR | 1.5 / 16 "X12 | Z3 / 4 "X14 | 22X1,5 | 49 | 45.2 | 33 | |||
1JN9-16-20OR | 1.5 / 16 "X12 | Z1.1 / 4 "X11.5 | 22X1,5 | 54 | 60,5 | 41 | |||
1JN9-20OR | 1.5 / 8 "X12 | Z1.1 / 4 "X11.5 | 28X1.5 | 55,5 | 54,5 | 41 | |||
1JN9-20-16OR | 1.5 / 8 "X12 | Z1 "X11.5 | 28X1.5 | 55,5 | 59.6 | 41 | |||
1JN9-20-24OR | 1.5 / 8 "X12 | Z1.1 / 2 "X11.5 | 28X1.5 | 59.4 | 63 | 48 | |||
1JN9-24OR | 1.7 / 8 "X12 | Z1.1 / 2 "X11.5 | 32X1,5 | 62,5 | 63 | 48 | |||
1JN9-24-20OR | 1.7 / 8 "X12 | Z1.1 / 4 "X11.5 | 32X1,5 | 62,5 | 63 | 48 | |||
1JN9-32OR | 2.1 / 2 "X12 | Z2 "X11.5 | 48X2 | 75.4 | 67,5 | 63 | |||
D NB20 0 NB50 0 NB20 0 NB30 0 Nu t ib d sleev e shoul d b e teb d nyias muaj nyias.h e nu t NB20 0 ib d sleev e NB50 0 kuv s suitabl e fo r metri c raj, th e nu t NB20 0 ib d sleev e NB30 0 kuv s suitabl e fo r xy h hlab ntxhoo . | |||||||||
